MEMOPOWER-III RT Rack Battery Cabinet 240Vdc – MP BR20240

Rack Battery Cabinet for RT 6 and 10 kVA Online UPS Systems

The MP BR20240 is a purpose-built rack battery cabinet designed to extend the runtime of MEMOPOWER-III RT 6 kVA and 10 kVA online UPS units. As a dedicated rack battery cabinet UAE businesses can deploy in standard 19-inch racks, it delivers a nominal 240Vdc output through a pre-installed bank of 20 sealed lead-acid batteries. The result is a structured, space-efficient power continuity solution for data centres, server rooms and critical infrastructure environments.

Key Technical Specifications

Battery Configuration

The cabinet houses 20 units of 12V 9Ah batteries. Each battery is factory-installed and wired to deliver the required 240Vdc bus voltage. This fixed configuration eliminates field assembly errors and ensures consistent electrical performance from the moment of installation.

Enclosure and Form Factor

The unit occupies 3U of rack space within a 440 mm × 680 mm × 131 mm chassis. The compact depth and standardised width allow straightforward integration into existing rack infrastructure without modification. The assembled weight is 63 kg; adequate floor load capacity and rack structural ratings should be verified prior to installation.

Compatibility

The MP BR20240 is rated for use with MEMOPOWER-III RT 6 kVA and 10 kVA online UPS models. Pairing the cabinet with a compatible UPS extends autonomy during mains failures, supporting business continuity requirements across telecommunications, finance and industrial applications.

NEWCOM Distribution Assurance

NEWCOM Computer Systems supplies the MP BR20240 as an authorised IT distributor serving the UAE, Bahrain and Oman. Each unit is sourced through verified channels, backed by structured after-sales support, and available for procurement by resellers and enterprise end-users across the region.
